I finally installed the trunk lock cylinder today. The small bracket with the clip was riveted in so I drilled it out. The cylinder came out pretty easy. I made a small scratch in the paint with the screw driver I was using as a prybar. The new cylinder was practically identical but the new rod was too long. My original is shorter because I have an electric trunk release I'm assuming. The new cylinder had some casting burrs which I filed off. One burr was where the gasket goes which would definitely gone through because the one that came with the kit were chintzy as hell. My old ones were not usable so I went ahead and used the new ones. The kit didn't have the foam that goes on the underside of the clip so I used a heat shrink wrap and some 3M adhesive. That worked pretty good. The new clips look nice but I couldn't use it because the old one has the mounting "clip" with the screw hole in one piece. The original was in good shape due to a lot of undercoat (?) covering it. I cleaned it up, shot some flat black on it and was ready to install. The new cylinder went right in. When I tried to put the original clip in it didn't want to go. I nudged it with a ballpeen a little at a time, checking to make sure the cylinder wasn't binding up. It finally went in. VERY SNUG! It will be a pain in the *ss to get back out. I even found a torx head screw that fit. The 2nd scratch was made with the ballpeen. Sucks but the lock looks factory. Back in business!

View attachment 110017View attachment 110016View attachment 110015I finally installed the trunk lock cylinder today. The small bracket with the clip was riveted in so I drilled it out. The cylinder came out pretty easy. I made a small scratch in the paint with the screw driver I was using as a prybar. The new cylinder was practically identical but the new rod was too long. My original is shorter because I have an electric trunk release I'm assuming. The new cylinder had some casting burrs which I filed off. One burr was where the gasket goes which would definitely gone through because the one that came with the kit were chintzy as hell. My old ones were not usable so I went ahead and used the new ones. The kit didn't have the foam that goes on the underside of the clip so I used a heat shrink wrap and some 3M adhesive. That worked pretty good. The new clips look nice but I couldn't use it because the old one has the mounting "clip" with the screw hole in one piece. The original was in good shape due to a lot of undercoat (?) covering it. I cleaned it up, shot some flat black on it and was ready to install. The new cylinder went right in. When I tried to put the original clip in it didn't want to go. I nudged it with a ballpeen a little at a time, checking to make sure the cylinder wasn't binding up. It finally went in. VERY SNUG! It will be a pain in the *ss to get back out. I even found a torx head screw that fit. The 2nd scratch was made with the ballpeen. Sucks but the lock looks factory. Back in business!
I had the same problem when switching to black locks on my Cutlass. That lock retainer is a PITA to get right. I grinded and filed the edges to get it to fit the new lock. I also dread the day it needs to be removed!

I got the door locks too. Keyed different than original. The door locks are in fine shape so I will just pack the extra key for the few times I actually need to get into the trunk.
